SWKD-6.0HFV Vacuum Wood Dryer Kiln

SWKD-6.0HFV wood dryer is a kind of small capacity high frequency vacuum kiln which is suitable for small sawmill factory, furniture manufacturer, guitar maker and other carpentry industries

dryer delivery

SWKD-6.0HFV Vacuum Wood Dryer Kiln

High frequency vacuum wood dryer machine is advanced wood drying equipment, which is powered by electricity and without boiler, environment friendly and easy to handle with.

Compared with conventional kiln dryers, high frequency vacuum wood dryer machine’s capacity is small but flexible, less factory space needed; efficiency is much higher (more than 10 times faster than kiln dryer). After seasoning, timber is kept straight and in high quality without cracking.
Out-turn of timber increases. HF vacuum wood dryer machine is the best choice for small and medium furniture manufacturers.

Specification of SWKD-6.0HFV Vacuum Wood Dryer

1,The high-frequency characteristics determines its unique advantages in mahogany and hardwood lumber drying, It only take 6 days for

2,thickness mahogany wood to reach 6-8%MC from 30-40% moisture content. And the drying result will be uniform moisture content, no bending and no cracking.

Model SWKD-6.0HFVHigh Frequency Vacuum Wood Dryer
Capacity 6.6 cubic meters per full load
Out Dimension 6500*1916*2006mm
Timber Cart Size 5000*1200*1100mm
Max Length of Wood 5000mm
High Frequency 6.78MHz
Vacuum pressure -0.093Mpa
Weight(kg) 7000

Main Features of SWKD-6.0HFV high frequency vacuum wood dryer

      1.Stable drying without defects

The wood is drying under vacuum condition,it is Low boiling point of water,it can be vaporized at 50℃.

Low temperature drying solves the problems of wood cracking, deformation and discoloration, especially for precious timber sensitive to temperature.

  1. Fast drying

High Frequency medium heating make the wood heated very fast, Temperature Gradient of Internal High and External Low and vacuum pressure make water dischaged out very quickly.The 8cm thick Africa rosewood from 40-50% moisture content only take 7 days to reach 8-10% moisture content.

  1. High quality drying result

High frequency vacuum wood dryer machine equipped with hydralic pressure system on top, the hydralic pressure system supply more than 4 tons presser on the wood stacking to prevent wood deformaing and bending.We use stainless steel 304 to make the pressure plate.

  1. Easy operation

PLC control system and Pneumatic system make it is easy to opetat.Automatic drying make it no need staff on duty during the drying process.

  1. High quality high frequency vacuum wood dryer machine

Our high frequency vacuum wood dryer machine is made of stainless steel to avoid corrison and rust.

Drying result

Some typical wood speices moisture content test after finish the dyring process by hf vacuum dryer kiln.

If you are suffering from cracking, bending, and can’t bear the long drying process.  it’s time to use hf vacuum  kiln

Our Customers

Many customers from the world are benefitting from the high frequency drying technology, if you want make your drying process easier and faster, welcome contact us

Vacuum kiln in the Unite States

Vacuum kiln in the Vietnam

Vacuum kiln in the Unite States

Why choose us Shuowei?

We do our best to provide you with better service and support for the end users of this HFV machine drying kilns.

Rich experience: Focused on the wood drying industry for more than 30 years, Shuiowei has mastered the drying methods of various wood species, and has most collected comprehensive drying data.

Strong R&D Capacity: There is a professional engineering team in Shuowei, it is led by two drying experts with more than 30 years experience and 12 young engineers who have been in this field for 6-10 years, it could provide customers with professional technical support and wood drying project solutions.

Customized services: According to the customers’ requirements,we can customize the exclusive equipment which is suitable for the work conditions and needs

After sales service: Super long warranty, free replacement of accessories within the warranty period, free after-sales service for life, 24-hour after-sales service all day, and solve after-sales problems anytime and anywhere

Strict Quality control – For electronic components we adopt the best ones (Schneider brand) , and Stainless steel is used for anti-corrosion vacuum oven. The equipment has been tested throughout the production and before leaving the factory to ensure the operation quality in aspects of power, pressure, air tightness etc., It has passed the all-round quality inspection of SGS, BV and other international testing institutions.

High praise from customers: The customers are all over the world including United States, Canada, South Korea, Japan, Indonesia, Thailand, Vietnam, Malaysia, Australia, New Zealand, European countries and Africa. The industry involves furniture factory, floor factory, cabinet factory, wooden door factory, wooden handicraft factory, etc., Shuowei has been highly praised by customers
